1. 泵 Pump
2. 泵體 Casing
3. 泵蓋 Casing cover
4. 葉輪 Impeller
5. 葉輪螺母 Impeller cap
6. 聚四氟乙烯 Teflon
7. 泵體密封環 Casing ring
8. 葉輪密封環 Impeller ring
9. 底座 Base
10. 底板 Under plate
11. 電機 Motor
12. 青稞紙 Highland barley paper
13. 過濾網 Filter net
14. 油杯 Oil cup
15. 油標 Oil level sight glass
16. 支撐管 Support column
17. 出液管 Discharge pipe
18. 密封墊 Gasket
19. 導流套 Battle
20. 螺栓 Bolt
21. 雙頭螺柱Stud
22. 吊環螺釘 Eyebolt
23. 螺母 Nut
24. 圓螺母 Disc nut
25. 隔板 Interstage diaphragm
26. 副葉輪Auxiliary impeller
27. 填料函Stuffing box
28. 填料環 Seal cage
29. 填料 Packing
30. 水封環 Water seal cage
31. 填料壓蓋 Gland cover
32. 機械密封 Mechanical seal
33. 機械壓蓋 Mechanical seal cover
34. 支腳 Supporting foot
35. 地腳螺栓 Foundation bolt
36. 膜片式聯軸器 Diaphragm coupling
37. 聯軸器罩 Coupling guard
38. 墊圈 Washer
39. 墊 Gasket
40. 鍵 Key
41. 銷 Pin
42. 甩水圈 Thrower
43. 甩油環 Lubricating ring
44. 防塵盤 Deflector
45. 調整墊 Adjust ring
46. 軸用彈性擋圈 Circlips for shaft
47. 孔用彈性擋圈 Circlips for hole
48. 止動墊圈 Tab washer
49. 鉚釘 Rivet
50. 緊定螺釘 Set screw
51. 上墊片 Upper gasket
52. 下墊片 Lower gasket
53. 軸 Shaft
54. 軸承 Bearing
55. 軸承箱體 Bearing support
56. 軸承架 Bearing frame
57. 軸承壓蓋 Bearing cover
58. 軸套 Shaft sleeve
59. 軸承套 Bearing sleeve
60. 軸承襯 Bearing bush
61. 彎管 Pipe bend
62. 管堵 Plug
63. 管接頭 Nipple
64. 銘牌 Nameplate
65. 轉向牌 Arrow plate
66. 警示牌 Warning board
67. 法蘭 Flange
68. 電機架 Motor frame
69. 潤滑系統 Lubrication system
70. 油封 Oil seal
71. 注油堵 Oil filler plug
72. 透明有機玻璃 Transparency organic glass
